PACKAGING & STORAGE
VpCI®-388 is available in 5 gallon (19 liter) pails, 55 gallon (208 liter) metal drums, liquid totes, and bulk. Keep product from freezing.
Product shelf life is 1 year.

CHARACTERISTICS/TECHNICAL DATA

Volume Solids	26.70%
Gloss (ASTM D532)	NA
VOCs (ASTM D3960)	0.2 lbs/gal (24 g/l)
Viscosity	5,000-15,000 Centipoise
Pencil Hardness (ASTM D3363)	NA
Spreading Rate	428 sq.ft/gal @ 1.0 mills DFT (10.5 sq.m/l @ 25 μm)
Weight per Gallon	8.57 lbs/gal (1.02 kg/l)
Flash Point	>200°F (93°C)
Recommended DFT	2.0-3.0 mils (50-75 μm)
Recommended WFT	7.5-11.25 mils (187.5-281.5 μm)
Dry to Touch	20-30 min
Dry to Handle	45-60 min
Recoat Time	NA
Force Dry	15-20 min @ 150°F (65°C)
Full Cure	3-7 days
Salt Spray (ASTM B117)	200 hrs
Humidity (ASTM D1748)	200 hrs
Adhesion (ASTM D3359)	5B
Flexibility (ASTM D522)	1/2" mandrel (1.27cm)

APPLICATION
Surface Preparation
Substrate should be free of grease, oil, dirt, fingerprints, drawing compounds, rust inhibitors, or any other surface con- tamination that could affect adhesion. For structural steel applications, Cortec® recommends a minimum of a NACE #3/ SSPC-SP6 commercial blast clean. Consult Cortec® and/or test system adhesion prior to full scale application.

Note: Make sure dew point is more than 5°F (2°C) less than air temperature for application. Power agitate to a uniform consistency using a “squirrel cage” type mixer, hand-held drill mixer, or other equivalent method. VpCI®-388 can be applied by spray, roll, brush, or dip.

Typical Equipment Setups
HVLP / Conventional Spray
•Tip .009”-.021” *dependent upon pressures and viscosity
•Air Pressure 45-55 psi
•Fluid Pressure 10 psi
•Fluid hose should be 3/8” (0.95 cm) I.D. with a maximum length of 50 feet (15.2 m). Pot should always have dual regula- tion and be kept at same elevation as spray gun.

Air Assisted Airless / Airless
•Tip .015”-.035” *dependent upon pressures and viscosity
•Pressure 1800-2500 psi
•Hose should be 3/8” (0.95 cm) I.D. minimum, but a ¼”
•(0.64 cm) I.D. whip end section may be used for ease of application. A maximum length of 100 feet (30.5 m) is suggested.

Cleanup
Clean tools/equipment immediately after use with water when coating is still wet. When dry, use Butyl Cellusolve or MEK. Follow mfg’s safety recommendations when using any solvent.
